我们采用优质材料生产高质量产品！36 多年来，红星公司一直致力于矿山和砂石行业广泛使用的筛分介质的工程设计和制造。
我们采用优质材料生产高质量产品！36 多年来，红星公司一直致力于矿山和砂石行业广泛使用的筛分介质的工程设计和制造。
![{$r[alt] ? $r[alt] : $title}](https://www.hongxingshaiwang.com/uploadfile/2024/1115/thumb_500_500_20241115090809350.jpg)
![{$r[alt] ? $r[alt] : $title}](https://www.hongxingshaiwang.com/uploadfile/2024/1115/thumb_500_500_20241115090809595.jpg)
![{$r[alt] ? $r[alt] : $title}](https://www.hongxingshaiwang.com/uploadfile/2024/1115/thumb_500_500_20241115090809711.jpg)
![{$r[alt] ? $r[alt] : $title}](https://www.hongxingshaiwang.com/uploadfile/2024/1115/thumb_500_500_20241115090810544.jpg)
![{$r[alt] ? $r[alt] : $title}](https://www.hongxingshaiwang.com/uploadfile/2024/1115/thumb_125_125_20241115090809350.jpg)
![{$r[alt] ? $r[alt] : $title}](https://www.hongxingshaiwang.com/uploadfile/2024/1115/thumb_125_125_20241115090809595.jpg)
![{$r[alt] ? $r[alt] : $title}](https://www.hongxingshaiwang.com/uploadfile/2024/1115/thumb_125_125_20241115090809711.jpg)
![{$r[alt] ? $r[alt] : $title}](https://www.hongxingshaiwang.com/uploadfile/2024/1115/thumb_125_125_20241115090810544.jpg)
Anti-clogging self-cleaning screen Mesh provides effective solutions for sticky and moist materials. The unique crimped and bonded wire structure prevents material blockage, improves throughput, and guarantees consistent performance, especially in wet screening applications.
Self-Cleaning Screens are advanced anti-blinding screening meshes engineered to reduce clogging, material buildup, and downtime in challenging screening conditions. Manufactured with specially crimped or independently vibrating wires, each wire moves freely during operation to prevent blinding, pegging, and blocking—particularly when handling damp, sticky, or fine materials.
Widely used in mining, aggregate, coal, and asphalt processing, self-cleaning screens deliver higher screening efficiency and stable performance worldwide.
Mesh Range: 2 mm – 60 mm
Wire Diameter Range: 1.37 mm – 9 mm
Wire Material: High Carbon Steel, Spring Steel, Stainless Steel (Optional)
Panel Width: Up to 2,500 mm
Panel Length: Custom to Vibrating Screen Type
Edge Options: Hook Edge, Flat Bar, Bolt-Down Edge
Excellent anti-blinding and anti-clogging performance
Higher screening efficiency and throughput capacity
Reduced downtime and maintenance costs
Longer service life compared to conventional woven wire screens
Ideal for wet, sticky, and difficult-to-screen materials
Self-cleaning screen mesh is widely used in industries where traditional wire screens struggle:
Mining and mineral processing
Quarry and aggregate production
Coal screening and washing plants
Sand and gravel classification
Asphalt mixing plants
Recycling and waste separation
Type 1 -Diamond holes with PU support strips
Type 2 -Wave holes with PU support strips
Type 3 -Triangle holes with PU support strips
Type 4- piano wire screen with PU support strips
Type 5- piano wire screen-Removable support bar
Type A -piano wire screen
Type B -piano wire screen
Type 1
Type 2
Type 3
Type 4
Type 5
Type A -piano wire screen
Type B -piano wire screen
Red Star Wire Mesh provides custom self-cleaning screens and OEM manufacturing services tailored to your vibrating screen model, capacity requirements, and material characteristics. Custom aperture sizes, wire diameters, panel dimensions, and edge types are all available to ensure optimal screening performance.
Type 1
Type 2
Type 3
Type 4
Type 5
Type 6
Type 7
Type 8
Type 9
Both Hooks Down
Both Hooks Up
One Hook Up and One Hook Down
Red Star Wire Mesh Manufacturing Co., Ltd. is a globally recognized supplier with strong technical strength and large-scale production capability in the mining screen mesh industry.
Established in 1989 with 36 years of manufacturing experience
Factory area of 58,730 m² with five specialized production workshops
Over 260 sets of advanced production and testing equipment
Dedicated self-cleaning screen workshop
4000 m² R&D center for new wear-resistant materials
18 patented screening products
Drafting unit for China mining anti-blocking self-cleaning screen standards
ISO9001, ISO14001, ISO45001 certified manufacturer
From raw wire processing to final inspection, every self-cleaning screen panel is manufactured under strict quality control procedures. Advanced wire treatment, precise forming, and comprehensive testing ensure consistent performance in harsh operating environments.
Looking for a dependable Self-Cleaning Screens manufacturer, supplier, or OEM partner? Contact Red Star Wire Mesh today for competitive pricing, technical consultation, and customized screening solutions for your application.
